GLM-2000 Label Applicator

For flat, square and cylindrical containers

The GLM-2000 applies labels on one or two sides of flat, square or cylindrical containers with maximum precision and flexibility. It reaches up to 100 units/min in continuous labeling (and up to 25 units/min in Stop&Go mode), making it ideal for demanding production lines.

Contact



Everything that makes the GLM-2000
an efficient solution

one or two-sided labeling

One- or two-sided labeling
Applies side and opposite-side labels with high precision, adapting to flat, square or cylindrical containers.

high production speed

High production speed
Up to 100 units/min in continuous mode and 25 units/min in Stop&Go mode, ensuring efficiency in fast or intermittent lines.

label head and conveyor

Label head and conveyor
Two adjustable heads and a 2800 mm × 110 mm conveyor ensure smooth movement and easy integration into the production line.

modular design and touchscreen

Modular design and touchscreen
Modular stainless steel frame and 7” TFT touchscreen for fast and intuitive adjustments.




PDF datasheet

GLM-2000 Technical Data Sheet

Download the complete GLM-2000 technical data sheet with full specifications, configuration options, and detailed performance data.

Download

Main technical features
Container type Square, flat and cylindrical
Label type Self-adhesive
Label application 1 or 2 labels (side and opposite side)
Operating speed Up to 100 units/min (continuous) / 25 units/min (Stop&Go mode)
Label size (max.) Height: 190 mm / Length: 200 mm
Container size (max.) Width: 100 mm / Length: 150 mm / Height: 300 mm
Equipment dimensions 3000 × 1000 × 1500 mm
Equipment weight 180 kg
Power supply 220 V / 50–60 Hz
Labeling system and structure
Material and frame Modular stainless steel
Display 7” TFT touchscreen
Applicator head 2 heads with height adjustment
Side aligners 2 aligners for precise positioning
Top container holder Stabilizing device during labeling
Container conveyor 2800 mm × 110 mm
End-of-line tray Yes
Support table Stainless steel 800 × 700 × 800 mm
Options
Rotary presser with side wall For precise labeling on round containers
Hot-stamping coder Prints dates, batch numbers and other variable data
Fork sensor Accurate detection of transparent labels
Belt conveyor Enables efficient container handling on the line
