GMD-S Metal Detector

For sausage filling lines with automatic stuffing systems

The GMD-S metal detector is specifically designed for sausage production lines equipped with automatic filling systems. Its outstanding performance ensures accurate detection of metallic contaminants even in dense mixtures or high-viscosity food pastes.

Contact



Everything that makes the GMD-S
a reliable solution

metal detection

Metal detection
Detects ferrous, non-ferrous and stainless-steel metals in products with high density and high viscosity.

full compatibility

Full compatibility
Easily integrates with calibration equipment via gear link systems, maintaining precise line synchronization.

mobile structure

Mobile structure and design
Its mobile design allows quick and safe installation and easy integration with the most common filling systems.

adjustable height

Adjustable height
Adjustable inlet height between 950 and 1250 mm using a hand crank, ensuring compatibility with various production lines.




PDF datasheet

GMD-S Technical Data Sheet

Download the complete GMD-S datasheet with full specifications, configuration options and detailed technical information.

Download



Main technical features
Inlet height 950 – 1250 mm (adjustable with hand crank)
Max. outlet pressure 55 bar (rotary slide valve 40 bar)
Pipe connection Rd 80 × 1/4” / HP
Free pipe diameter 57 mm
Weight 150 kg
Operating conditions
Storage temperature −10 °C … +60 °C
Operating temperature −10 °C … +50 °C
Protection class IP69K
Filling machine control cable Includes cable and connector (specify filling machine when ordering)
Electrical connection 230 VAC; 50–60 Hz; 100 W
Pneumatic connection Max. 6 bar, filtered, dry and oil-free; self-sealing coupling – NW 7.2 fitting
Options
Rejection system Pneumatic piston
